CWFA
|
|
 |
|
|
|
|
|
| |
| |
FEATURES
• Woltmann water meter horizontal and verticaly assembly
• Treatment of limpid, torbid and strongly raw waters
( p o t a b i l i z a t i o n p rocess, chlorination, scaling
neutralization and prevention)
• Epoxy coated cast iron housing
• Working temperature: cold water 0 to 50°C
• Direct reading on 6 digits totalizer
• Reed contact with 109 operations
• Electrical features of reed contact:
- Max voltage 250 VAC, 200 VDC
- Max current 1.0A
- Max power 10VA
- Insulation tension 400Vac |
|
| |
| |
|
|
|
| |
| |
|
|
|
|
|
|
|
| |
| |
|
ORDER REFERENCE
- CWFA0100 - 50 mm - 2"
- CWFA0105 - 65 mm - 2 1/2"
- CWFA0110 - 80 mm - 3"
- CWFA0115 - 100 mm - 4"
- CWFA0125 - 150 mm - 6"
- CWFA0128 - 200 mm - 8"
OPTIONS
• CWCA: with dry plate (90°C - 16 bar)
• CWFI: with dry plateo (30°C - 16 bar) |
|
|
|
|
|
| |
|
