FA
|
|
 |
|
|
|
|
|
| |
| |
"FA" WOUND PP CARTRIDGES
GENERAL FEATURES
These filtering cartridges are made winding carefully selected
fibers (FDA certificate) around a central core which carries out
the function of support.
The type of winding makes a structure progressively selective
and depending on the type of tension and torsion of the fibers,
it guarantees the different degree of filtration.
This technique allows the contaminan to be trapped on all the
depth of the filtering body with a consequent accumulation
of solid material, without causing however high differential
pressure values (pressure drop).
The absolute absence of binding substances, allows a good
chemical compatibility with any type of fluids to treat, offering
a high versatility of use.
TECHNICAL SHEET:
- Maximum operating temperature: ___________________ 80° C
- Maximum operation forward pressure: ____________ 6 bar 20°
- Recommended replaceable pressure drop: _________ 0,8 bar
- Efficiency: _____________________________________________ 80%
- Flow Rate: ______________________________________ see diagram |
|
| |
| |
|
|
|
| |
|
